SECTION 3: MACHINERY AND EQUIPMENT 3-1: GARBAGE COLLECTING VEHICLE

CODE NO. ITEM QTY

03-01-01156

CHASSIS CAB: 4X2

ENGINE: 6 CYLINDER, 4 STROKE. TURBOCHARGER

POWER; NOT LESS THAN 240 HP.

CLUTCH : SINGLE PLATE

GEAR BOX : 8 SPEED

G. V. W : NOT LESS THAN 19 TON

PAYLOAD : NOT LESS THAN 11 TON

TIER SIZE : 1200 X 20 DISK TYPE

CAPACITY : 16 m^ COMPACT RATIO: 6:1 WITH SPARE PARTS FOR TWO YEARS OPERATION

qty300

3-2: STREET SWEEPERS

CODE NO.	ITEM	QTY
03-01-01157	G.V.W: 14-16 TON. DIESEL ENGINE 4 CYLINDERS DIRECT INJECTI ON PUMPS. POWER 80-110 HP AUXILIARY ENGINE : 4 CYLINDER, WATER COOLED, DIRECT INJECTION PUMP, POWER 80-100HP BODY: CONTAINER CAP: 8-10 M3 SWEEPING SPEED : 0-20 KM/H AIRFLOW CAP: 8-10 M3 /H. WATER CONTAINER VOLUME : 1-1250 M3 CENTER BRUSH: 400 MM 0X 1500 ML MAX. SUCTION DEPTH : 200 MM WITH REAR HOSE FOR SUCTION MAX. SWEEPING WIDTH NOT LESS THAN 3500 MM WITH SPARE PARTS FOR TWO YEARS OPERATION	10
3-3: JETTING VEHICLES 3-3'
CODE NO.	ITEM	QTY
03-01-01158	CHASSIS CAB '4X2 ENGINE: 6 CYLINDER, 4 STROKE. TURBOCHARGER POWER: NOT LESS THAN 200 HP. CLUTCH : SINGLE PLATE ; GEAR BOX : 8 SPEED G. V. W : NOT LESS THAN 19 TON PAYLOAD : NOT LESS THAN 12 TON ; TIER SIZE : 1200 X 20 DISK TYPE TANK CAPACITY : 9000 L PUMP PRES. NOT LESS THAN 200 BAR. FLOW 300 L/MIN. WITH SPARE PARTS FOR TWO YEARS OPERATION	20

3-4: CESSPIT EMPTIER

CODE NO.	ITEM ^UOT ? .		QTY
03-01-01159	CHASSIS CAB : 4 X 2 ENGINE: 6 CYLINDER, 4 STROKE. TURBOCHARGER POWER: NOT LESS THAN 240 HP. CLUTCH : SINGLE PLATE GEAR BOX : 8 SPEED G. V. W : NOT LESS THAN 19 TON PAYLOAD : NOT LESS THAN 12 TON TIER SIZE : 1200 X 20 DISK TYPE TANK CAPACITY : NOT LESS THAN 10000 L FLOW RATE :600 m^ /h WITH SPARE PARTS FOR TWO YEARS OPERATION		15
